Flush Door
BWP Flush Doors
IS 2202
BWP Flush Door · IS 2202
Solid doors that stay true for years
BWP Flush Doors from Sitco Ply are made from selected pinewood frames and evenly sized batons. Our high-density block board doors provide excellent insulation against dust, heat and sound.
Made from quality imported timber, they are highly resistant to borers and termites, and offer durability and long-lasting performance for homes and commercial spaces.
- Selected pinewood frames with evenly sized batons
- High-density block board core
- Insulation against dust, heat and sound
- Highly resistant to borers and termites
Areas of application
Where to use Flush Door
Suitable for residential and commercial doors and for interior and exterior applications, offering durability, insulation and long-lasting performance.
Quality report
Tested to IS 2202
Laboratory results for Sitco Flush Door compared with the Indian Standard requirement.
| No. | Test | IS : 2202 Requirements | Sitco result |
|---|---|---|---|
| 1 | Moisture Content (%) | 10 - 12 | 11 |
| 2 | Flatness of Shutter (twist, cupping and warping) | Not more than 1 mm | 0.5 mm |
| 3 | Local Planeness (surface smoothness) | Not more than 0.5 mm | 0.3 mm |
| 4 | Impact Indentation | Not more than 0.2 mm by a weight of 0.5 kg | Pass |
| 5 | Flexure Resistance (residual deflection) | Not more than 2 mm | 1.1 mm |
| 6 | Edge Loading | a) Residual deflection not more than 0.2 mm b) Lateral buckling not more than 1.5 mm |
0.15 mm 0.08 mm |
| 7 | Shock Resistance | No visible damage after 25 blows of 5 kg | Pass |
| 8 | Buckling Resistance | a) Initial deflection not more than 40 mm b) Residual deflection not more than 5 mm |
25 mm 2 mm |
| 9 | Slamming of the Shutter | No visible impact after 25 impacts of 15 kg | Pass |
| 10 | Misuse of the Shutter | No permanent deformation after the test | Pass |
| 11 | End Immersion | No delamination after immersion | 2.8% |
| 12 | Adhesion of Plies | Excellent | Excellent |
| 13 | Glue Adhesion | No delamination of the glue line | Pass |
| 14 | Screw Holding Strength (kg) | > 200 | 350 |
| 15 | Preservative Treatment | Two Tier Treatment: 1. Lumber and Veneers are treated with preservatives 2. Glue Line is fortified with non-leachable organophosphorous compound (USA technology) |
Pass Pass |
| 16 | Specific Gravity | 0.60 | 0.60 |
| 17 | Water Absorption | < 2% | 1% |
| 18 | Nail Holding Strength (kg) | > 100 | 250 |
